Machine introduction :This machine have been widely used in manufacturing,chemical,food,beverage and other industries.It is especially designed for high viscosity liquid Easily controlled by computer (PLC), touch screen control panel . It is characterized by its totally close from ,submerged filling ,high measurement accuracy , compact and perfect feature ,liquid cylinder and conduits disassemble and clean . It may also suited various figure containers . We utilize high-quality stainless steel frames , international famous brand electrical components , the machine is applied to GMP standard requirement
|Number of filling heads||4~20 head (depending on the designing)|
|Filling capacity||according to your requirment|
|Filling type||piston pump|
|Filling speed||500ml-500ml: ≤1200 bottles per hour 1000ml: ≤600 bottles per hour|
|Program control||PLC + touch screen|
|Main materials||304 stainless steel, 316 used in food industry|
|Conveyer belt Speed||0-15m/min|
|Conveyer belt Distance away from the ground||750mm±50mm|
|servo motor||Panasonic Japan|
|Capacity of material tank||200L (with liquid level switch)|
|Protective device||Outage alarm on shortage of liquid in the reservoirtank|
|Power source||220/380V, 50/60HZ or customized|
|Host weight||about 900kg|
1. All pipe use quick-change connector.
2. Height and space between filling heads can be changed quick and easy to operate.
3. All filling valve use ESG valve instead of traditional valve by general manufacturer.
4. All filling heads can be diving from the bottom of bottle to start filling
50ML-5L plastic bottles, glass bottles, round bottles, square bottles, hammer bottles are applicable
Hand sanitizer, shower gel, shampoo, disinfectant and other liquids, with corrosive liquids, paste are applicable
The machine use the straight line into the bottle, automatically arrange caps, sleeving caps ,caps after sleeve and check will go into the gland system by the clamping belt.Due to the lid-cover flat belt design have a drop of slop, the caps after press will become more and more tightly.The machine has simple structure, convenient adjustment, production speed fast, high pass rate, after cap pressing has good performance, suitable for cap tighten (all sizes,screw,pump,sprayer flip cap and so on )
New capping design: Suitable for many materials. When you need to replace the bottle or cap, you only need to adjust the position of some parts without replacing any accessories. The speed of the cap sorter, conveyor, capping machine, and bottle clamping belt can be adjusted by buttons, which is suitable for each caps of similar specifications ,also can be customized
The latest tracking capping machine, using tracking capping, does not damage the bottle cap, speed, safety and stability, high efficiency capping.
The machine adopts multiple servo motors to control the upper and lower movements of the capping head. During the capping rotation process, the bottle moves continuously, and PLC controls the operation of the whole machine without harming the bottle or the cap.It also increases the speed and stability of production.
1.With servo drive motor, the cap can be rotated quickly and accurately without damaging the bottle or the cap.
2.Belt type cap feeding, can be added the bad and crooked cap elimination device.
3.Servo motor control bottle belt, adjustable speed, no liquid overflow or bottle pour phenomenon.
4.Adjustment mechanism is simple and convenient, and equipped with instruments, can be accurately positioned.
5.Portable capping head design, just change capping head, can meet the production of new bottle.
This machine id widely suitable for foodstuff, cosmetic, pharmaceutical, pesticide and other industries. It is single and double side labeling for flat, square and round bottle . Automatic controlled by computer (PLC)easy operating.No bottle no labeling. It can change specifications easily. It adopts servo motor, achieved closed loop control low malfunction rate. High efficiency. Fast speed.
1.Machine design beautiful, Using PLC automation control, simple operation, high precision label, fast production speed.
2. Servo motor control labeling,match with LEUZE Photoelectric,the accuracy is high.
3. Machine structure design is simple, easy to adjust.
|Power supply||AC220V ;50HZ (or according to client voltage requirement )|
|label length||6-300mm,label width:20-150mm|
|bottle size||flat or square lenght ≥40mm,20≤width≤160mm,20≤height≤ 300mm |
|Label inner diameter||76mm,Label outer diameter:350mm label precision:±1mm|
|Dimensions||1800L * 800W * 1600H mm|
The machine will be fixed and then packed in wooden cases.Fast Delivery!
Shanghai ALWELL have more than 2000 Square meters factory.
We have 10 years experience in the industry. Factory direct sale,we can prove very competitive price and durable quality guarantee Our main products are check weigher, metal detector, weight sorting machine, liquid filling machine, powder filling machine,Syringe filling machine,capping machine,labeling machine, and supporting production lines.
Our Services & Strength
We can fast delivery within 5 days at the earliest. We support OEM.
2.. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
3..We provide one year warranty
4.Well-trained & experienced staff are to answer all your inquiries in English and Chinese
5 .12 Months guarantee and life-long technical support.
6.Your business relationship with us will be confidential to any third party.
7. Good after-sale service offered, please get back to us if you got any questions.
We are manufacturer and we are located in Shanghai,China.
2.What kind of Transportation could you provide?And are you able to update the production process Information in time after placing our order?
Sea shipping, air Shipping, and international express. And after confirming your order ,we would keep you updated of production details of emails and photos.
3.How long is your warranty?
12 months free warranty, life-long maintenance.
4.Are you provide product metal parts and provide us technical guidance?
Wearing parts,for example, motor belt,Disassembly tool(free) are what we could provide.And we can give you technical guidance.
5.What are your company requests of payment terms?
TT,L/C,International Credit Card.
6. What is the validity time of the quotation?
15 days since quotation date
7. What is the delivery time?
Within 15 days after receipt of your deposit.
8. Are you a manufacturer?
Yes, we are a manufacturer, and we can provide the competitive price and good quality.
Remark: In view of our products model different ,widely used in many industries ,in order to improve communication efficiency .so pls note the size weight and name of testing product before send us inquiry .so we can choose the suitable one for you ,send detail and quotation to your email .thank you for your understanding .
