product description:
Introduction
This machine adopts PLC controller and color touch screen and made it possible for programmable control of the machine. It can perform the filling for ointment, cream jellies or viscosity material, tail folding, batch number embossing (include manufacture date) automatically. It's ideal equipment for aluminum/soft tube filling and sealing for cosmetic, pharmacy, foodstuff and bond industries.
Features
Features
(1)Full-automatically controlled by PLC. It is easy for display and operation by touch screen.
(2)Adopt the spring tube pucks ensuring the same height of sealed end.(3)Automatic mark-finding device
(4)This design can ensure the high filling accuracy with simple structure which is easy to remove and clean.
(5)Hot air inside sealed the tube, cold water circle-cooled the outer wall of the tubes. That ensured the effect of the sealing.
(6)Exhaust the harmful gases outdoors by fan.
(7)Highly clear stainless steel frame
(8)It's easy to operate between different sizes of tubes.
Main technical parameters
Model No. | Automatic tube filling sealing machine |
Ultrasonic Power | 2000W |
Ultrasonic Frequency | 20KHz |
Power Supply | AC 220V, 50/60Hz |
Delay Time/Weld Time/Seal Time | 0.01-9.99S |
Driven Mode | Pneumatic |
Stroke | 75MM |
Working Pressure | 0.4-0.7Mpa |
Tube Diameter Range | 10-50MM |
Tube Height Range | 50-250MM |
Filling Volume Range | A: 5-60 ml B: 10-120 ml C: 25-250 ml D: 50-500 ml |
Working Stations | 10 |
Hopper Volume | 30L |
Capacity | 20-60 tubes/min |
Packing Dimension | L*W*H 1310*1050*1760 mm |
Gross | 440 KGS |
