Product Description Full Automatic 3 in 1 Complete PET Bottle Juice hot filling Production MachineLUYE RCGF Series  is designed by our company with stable characteristic, advanced technology, nice appearance and complete function. The machine is mainly used for washing/filling/capping PET bottle jui

Featured Products

Product Description
Full Automatic 3 in 1 Complete PET Bottle Juice hot filling Production Machine
8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine


LUYE RCGF Series  is designed by our company with stable characteristic, advanced technology, nice appearance and complete function.
The machine is mainly used for washing/filling/capping PET bottle juice, tea drinks and all kinds of energy drink for hot filling. Only need to change a few spare parts that can suitable for filling pure water and mineral water.

We supply complete solution for the juice filling machine ,including Water treatment system /Juice mixing system / UHT Sterilizer / Washing filling capping machine / Code sprayer / Automatic labeling machine / Automatic packing machine / Automatic Palletizer system

EQUIPMENT TYPEFull automatic

APPLICATION FOR BOTTLE
Round or square bottle
Volume 200 - 2000ml
Diameter: Φ50~120mm

Bottle height:160~320mm

Diameter of bottle mouth: Φ25~38mm
CAPACITY PER HOUR2000~24000BPH
GUARANTEEFree warranty since12 months after installation & commissioning, or 15 month after delivery date
AFTER SERIVCELife- long maintenance

Different filling capacities
RCGF14-12-5  juice filling machine capacity :2000-3000 bottles per hour.
RCGF18-18-6  juice filling machine capacity :6000-8000 bottles per hour.
RCGF24-24-8 juice filling machine capacity : 8000-12000 bottles per hour.
RCGF32-32-10 juice filling machine capacity :12000-15000 bottles per hour.
RCGF40-40-12 juice filling machine capacity :18000-20000 bottles per hour
RCGF50-50-15 juice filling machine capacity :20000-24000 bottles per hour


WOULD LIKE TO KNOW MORE ABOUT LUYE MACHINE EQUIPMENTS, FEEL FREE TO SEND US AN INQUIRY!

8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine

ADVANTAGE
A) PLC and Touch screen full automatic control. Easy for operate
B) Fastly different bottle size replacement
C) Concise structure, reliable and durable, easy to maintain.
8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine


1.Washing part
Composes of bottle washing clamp, upper rotary plate, guide rail, water distributing plate, shield, water spraying device, water tray etc.
Bottle washing clamp rotates with the upper rotary plate, and open the bottle mouth clamp with elastic distortion when contacting the bottle feeding star wheel, which can clamp the bottle neck, then overturns at 180° along the guide rail, bottle mouth may become downwards for cleaning and drying the bottle with water, then overturn for 180°, bottle mouth becomes upwards and then conveyed with the star wheel; shield can prevent sprinkling of cleaning water; water distributing plate can deliver the cleaning water from the still parts to the rotary parts.


8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine2.Filling part
mainly composes of bottling barrel, bottling valve, guide rail, lifting device, bottle clamping lift device etc.
Bottle is conveyed to the bottling machine with the clamp plate of star wheel drive IV, bottling bottle clamp plate supports the bottle neck and rotates together with the bottling, and ascend along the guide rail and then open the bottling valve for bottling, after finishing bottling, it descend and loose the bottling valve, bottling valve may automatically close. Bottle is discharged from the bottling machine along the clamp plate of star wheel drive.
8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine

3.Capping part
composes of cap separating mechanism, capping machine and cap arranging mechanism.
Bottle is conveyed into the capping machine with 3# star wheel and then is clamped with the bottle clamping block; the cap is arranged by the cap arranging mechanism and then is delivered to the cap separating mechanism from the lower cap tank; cap separating mechanism can separate the caps, and capping head may ascend and remove the cap and press it onto the bottle mouth with cam; under the drive of gear, capping head tighten the cap on the bottle mouth along the shaft, and keep constant capping moment; the well capped bottle is delivered out with 4# star wheel. The capping machine is connected with cap separating mechanism, lower cap tank, cap arranging mechanism with harmonious combination through several movements for delivering bottle, delivering cap, holding cap and capping.


Auxiliary Equipment
8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine



1.RO WATER TRATMENT SYSTEM
•Stainless steel high pressure film shell
•All kinds of capacity indicator, pressure indicator, electricity magnetic valve, balance device and pipe valve system
•Online type pressure auto self-protection device •Online type electricity indicator (with stable compensation)
•System safe protecting and alarm system •Stainless steel frame

Choose the above equipment according to your Raw water report.
8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine

2.BOTTLE BLOWING MACHINE
Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.
Choose the above equipment according to your bottle design and PET preforms.
8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine

3.JUICE PRE-PROCESS SYSTEM
1 - High-shear emulsifying tank + Plate heat exchanger
2 - Mixing tank
3 - UHT sterilizer + homogenizer machine +Vacuum Degasser+ Buffer tank
4 - Hot water system + Hot water tank
5 - CIP cleaning system

Choose the above equipment according to your Juice materials and Production process.

8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine

4.LABELING MACHINE
Optional Equipment:
1)Heat shrink sleeve labeling machine
2)OPP Hot glue melt labeling machine
3)Self-adhesive labeling machine

Choose the above equipment according to your bottle design and label material.
8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine

4.PE FILM SHRINK WRAPPING PACKAGE MACHINE
Optional Equipment:
1)PE film shrink wrapping package machine
2)Half-Tray carton Shrink wrapping package machine
3)Carton package machine

Choose the above equipment according to your requirement and Packing material.


FAQ
1.ARE YOU MANUFACTURER OR TRADE COMPANY?

We are manufacturer, located in Zhangjiagang. We are Specialized in beverage machinery 30 years! Our company business is supply all kind of beverage filling machine, package machine, water treatment machine And complete line from A-Z for water, juice, carbonated drink, beer, Aluminum Can drink, all kind of bottle drink filling machine
2.WHAT'S THE ORDER PROCESS?
a. Inquiry-- Provide us all your clear requirements.
b. Quotation-- Official quotation form with all clear specifications.
c. Payment terms-- T/T 30% in advanced, balanced before shipment. We can talk about this when deal.
d. Shipping-- By sea, Detailed picture of package will be provided.
3.CAN YOU GIVE ME YOUR PRICE LIST?
Sorry, we are machine manufacturer, we have more than 100 items, and each machine have different bottle Type, weight, Voltage, Dimension, Capacity, Usage so on request. So please send me your detail request, then I will email you back the price.
4.WILL YOU HAVE SOME DISCOUNT?
a. To clients who bring repeat orders and large orders
b. Please contact us for Better Quote.
5.HOW CAN I INSTALL MY MACHINE WHEN IT ARRIVES?
We will send our engineer to go to buyer's factory to install, test machines, and train buyer's staff how to operate, maintain machines.



AFTER-SALES SERVICE
1.We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly
2.When you finish the preparation conditions, our fast and professional aftersales service engineer team will go to your factory to install the machine, give you the operating manual, and train your employee untill they can operate the machine well.
3.We often ask feed back and offer help to our customer whose machine have been used in their factory for some time.
4.We provide one year warranty.
5.Well-trained & experienced staff are to answer all your inquires in English and Chinese
6.24 hours for engineer response ( all services part 5days in customer hand by Intl' courier).
7.12 months guarantee and life-long technical support
8.Your business relationship with us will be confidential to any third party.
9.Good after-sale service offered, please get back to us if you got any questions.




LUYE MACHINERY COMPANY INTRODUCTION
SINCE 1989
8 Nozzles Juice Water Bag Filling Machine Liquid Filling Sealing Machine Juice Bag Filling Sealing Machine



LUYE has More than 30 years Professional Manufacturer of Turn-key Beverage Machinery.
  1. Installation, debug
    After equipment reached the workshop of customer, place the equipment according to plane layout we offered. We will arrange seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated producing capacity of the line. The buyer need to supply the round tickets and accommodation of our engineer, and the salary.
  2. Training
    Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.


  3. Quality guarantee
    We promise that our goods are all new and not used. They're made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. We promise that the products of this line could storage for one year without adding any aseptic.


.
